NameHaber Reactor [updated since 11.08.2023]
Person in chargeBaris Alkan, A. B. NgO
Comment

Updates;

  • A new NH3 MFC (I303) was added to the setup. Old NH3 MFC (I51) was deinstalled from the reactor.

Fast screening reactor for ammonia decomposition reaction (FHI at IRIS, Adlershof)

ApplicationAmmonia decomposition

Files

(5)
IdFileTimeCommentSizeAction
812 Gas calibration curve - NH3 - 200mlmin-1.pptx 2024-05-24 18:48:02 46.0 Kb
813 Haber flowchart V2.5.pptx 2024-05-24 18:48:02 930.7 Kb
814 Inventory number.jpg 2024-05-24 18:48:02 5.1 Mb
815 Isothermal zone of oven (15.09.2022).opju 2024-05-24 18:48:02 48.2 Kb
816 Isothermal zone of oven (15.09.2022).pdf 2024-05-24 18:48:02 5.4 Kb

Linked Entries

IdProjectAction
I173 Ammonia (NH3) - Mass flow controller (MFC) - 2.. Bronkhorst
I161 Carbon dioxide (CO2) - Mass flow controller (M.. Bronkhorst
I162 Ethylene (C2H4) - Mass flow controller (MFC) -.. Bronkhorst
I163 Argon (Ar) - Mass flow controller (MFC) - (for.. Bronkhorst
I164 Ammonia (NH3) - Mass flow controller (MFC) 30 .. Bronkhorst
I166 Reactor Oven (Klappofen) 1100°C LK1100-45-240-1 HTM Reetz GmbH
I167 NH3 detector (Binos 1.2, IR detector, Rosemount) ROSEMOUNT
I168 Two position actuator control module (VICI) VICI (Valco Instruments Co. Inc.)
I169 Temperaturregler 2-Kanal E-Kab. #4366 EUROTHERM
I170 PICO TC-08 Pico Technology
I171 Type K Thermocouple Electrotherm
I172 USB-Nano-485 convertor CTI
P12 Handbook AmmoRef project Saskia Heumann, Holger Ruland, Annette Trunsch..
